255 LPH Drop-In Fuel Module assembly for 09-14 F-150, 3.7/4.6/5.0/5.4/6.2 Flex Fuel 145" and 157" wheelbase. For extended range tanks.
These Drop-in modules have been designed to the highest quality standards to provide increased performance and fuel efficiency for most stock, turbo, and supercharged applications capable of supporting 550+ horsepower.
- Complete drop-in fuel module assembly
- Integrated fuel storage and filtration technology
- Built in, pre-calibrated fuel level sensors
- Plug and play wiring harnesses
- Capable of supporting 550+ hp right out of the box
- Designed for return line and pulse width modulation (PWM)
Information:
TU295HP
Application Summary:
| Year |
Make/Model |
| 2009-2014 |
Ford F-150 |
| 2010-2014 |
Lincoln Mark LT |
| Attributes |
| Application |
09-14 F-150, 3.7/4.6/5.0/5.4 Flex Fuel, 3.7/4.6/5.0/5.4 Flex Fuel |
| ASIN |
B06Y6L8Y8J |
| Average Flow Rating |
255, 255 |
| Brand |
Holley, Holley |
| California Proposition 65 |
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov |
| Category |
Air and Fuel Delivery |
| Clearance Category |
Air and Fuel Delivery |
| Country of Origin (Primary) |
US |
| Discount Percentage |
26-50% |
| Emission Code |
5, 5 |
| Free Flow GPH |
50, 50 |
| Free Flow LPH |
255, 255 |
| Fuel Filter Included |
Yes |
| Fuel Sending Unit Included |
Yes |
| Fuel System |
EFI, EFI |
| Fuel System Type |
EFI |
| Fuel Tank Pressure Sensor Included |
No |
| Fuel Type |
Gasoline / Ethanol / Methanol / E85, Gasoline / Ethanol / Methanol / E85 |
| Fully Open |
255 |
| Gasket Or Seal Included |
Yes |
| Gasket Or Seal Material |
Rubber |
| Grade Type |
Performance |
| Harmonized Tariff Code (Schedule B) |
8413301000 |
| Hazardous Material Code |
N |
| Height |
Standard |
| Housing Material |
Plastic |
| In Tank or External |
In Tank |
| Inlet Type |
Barb |
| Internal Or External Strainer |
External |
| Life Cycle Status Code |
Available to Order |
| Lock Ring Included |
No |
| Mounting Hardware Included |
No |
| NAFTA Preference Criterion Code |
B |
| Negative Ground |
Yes |
| Outlet Type |
Barb |
| part type |
Fuel Pump Module Assembly |
| Product Type |
Fuel Pump Module, Fuel Pump Module |
| Pump Type |
Electric |
| Regulator Included |
No |
| Resistance Ohms Empty |
16 |
| Resistance Ohms Full |
158 |
| SDR Required Flag |
N |
| Sub Category |
Fuel Pumps and Related Components |
| Universal Or Specific Fit |
Specific |
| Voltage |
12 |
| Warning |
California Proposition 65, California Proposition 65 |
| Warranty |
Limited 90 Day, Manufacturer's Limited 90 Day Warranty |
| GTIN |
00090127004357 |
