Holley EFI Intake Manifold 396, 402, 427, 454, 502 for 4150 Style Flange, Rectangular Port Heads
Holley EFI is excited to launch four new multi-point fuel injection intake manifolds for the big block Chevy. These new intakes are available to fit oval or rectangular port heads, and 4150 or 4500 style throttle bodies. These Intakes are ideal for converting your big block high performance or racing engine from carburetion to fuel injection. These intake manifolds were computer designed and dyno proven to produce more horse power and torque than other EFI manifolds. Each manifold package includes anodized and laser etched fuel rails, and two sets of mounting brackets (brackets allow use of 1.48" or 2.56" O-ring to O-ring injector lengths).
Holley EFI is excited to launch four new multi-point fuel injection intake manifolds for the big block Chevy. These new intakes are available to fit oval or rectangular port heads, and 4150 or 4500 style throttle bodies. These Intakes are ideal for converting your big block high performance or racing engine from carburetion to fuel injection. These intake manifolds were computer designed and dyno proven to produce more horse power and torque than other EFI manifolds. Each manifold package includes anodized and laser etched fuel rails, and two sets of mounting brackets (brackets allow use of 1.48" or 2.56" O-ring to O-ring injector lengths).
- Rectangle Port Dimensions: 2.28” High x 1.48” Wide
- 3500-8000 RPM power band
- 4150 carburetor mounting flange
- Height: Front 5.96", Rear 5.96"
- No EGR provisions
- Perfect for hard core drag racers in the NHRA Super Comp, Super Gas, and Street classes as well as IHRA Quick Rod, Super Rod, and Hot Rod categories
- Open plenum/single plane design
- Designed for today's larger cubic inch big block Chevy race engines
- Includes fuel rails and mounting brackets
| Attributes | |
| Basic Operating RPM Range | 3500-8000 |
| Brand | Holley EFI, Holley EFI |
| CNC Ported | No |
| Category | Air and Fuel Delivery, Intake Manifolds |
| Category Filter | Intake Manifolds |
| Clearance Category | Intake Manifolds |
| Color | Natural, Natural |
| Construction | Cast, Cast |
| Country of Origin (Primary) | CN |
| Cylinder Head Port Shape | Rectangle, Rectangle |
| Deck Height | 9.8 |
| EGR Port | No, No |
| Emission Code | 3, 3, Off Road |
| Engine | Chevy Big Block V8, Chevy Big Block V8 |
| Flange Style | 4150 Square Bore |
| Fuel Injectors Included | No, No |
| GTIN | 00090127716502 |
| Gasket Or Seal Included | No, No |
| Grade Type | Performance, Performance |
| Harmonized Tariff Code (Schedule B) | 8409915085 |
| Hazardous Material Code | N |
| Life Cycle Status Code | Available to Order |
| Manifold Type | High Rise, High Rise |
| Material | Aluminum, Aluminum |
| Plenum Finish | Natural, Natural |
| Product Type | EFI Intake Manifold, EFI Intake Manifold |
| RPM Power Band | 3500-8000, 3500-8000 RPM |
| SDR Required Flag | N |
| Sale Category | Air and Fuel Delivery |
| Single Or Dual Plane Type | Single Plane, Single Plane |
| Sub Category | Cylinder Block Components, Cylinder Block Components |
| Throttle Body Gasket Included | No |
| Vacuum Ports | Yes |
| Warning | California Proposition 65, California Proposition 65 |
| Warranty | Limited 90 Day, Manufacturer's Limited 90 Day Warranty |
| part type | Engine Intake Manifold, Engine Intake Manifold |
Holley EFI 300-563 Holley EFI Intake - Chevy Big Block V8 EFI
Product Information
- Brand: Holley EFI
- Product Number: 300-563
